Description
The 5 port solenoid valves series SQ was designed for applications which
demand high speed, high frequency, long life and a precise response time.
The SQ uses cassette style valves and manifolds, making it simple to
increase or decrease the number of stations on a DIN rail. Valves are
available with 12VDC or 24VDC rated voltage. Actuation options include 5
port single solenoid, 5 port double solenoid, and dual 3/2 ported.
Manifold variations for the SQ plug-in series include EX510 Gateway-type
serial transmission system, D-sub connector, flat ribbon cable connector,
PC wiring system compatible flat ribbon cable, terminal block box, or a
lead wire kit. The SQ plug lead units are available with D-sub connector,
flat ribbon cable connector or PC wiring system compatible flat ribbon
cable kits.
– Fluid: Air/inert gas
– Maximum operating pressure: 0.7MPa
– Effective area mm² (Cv factor):0.40 to 0.71
– Coil rated voltage: 12, 24VDC
– Power consumption (current):
24VDC; 0.4W DC (17mA), 12VDC; 0.4W DC (34mA)
– Ambient & fluid temperature: -10 to 50°C
Download SQ2x3x Datasheet by click the link Datasheet.
