Description
Siemens SIMATIC SIPLUS S7-1200 CPU 1211C PLC 6AG1211-1AE31-4XB0
Siemens SIMATIC SIPLUS S7-1200 CPU 1211C PLC compact CPU, for medial exposure with conformal coating based on 6ES7211-1AE31-0XB0.
6AG 1211-1AE31-4XB0 6AG1211-1AE31-4XB0 6AG12111AE314XB0
Model No.: S7-1200 PLC CPU 1211C S7-1211C
Power Supply: DC 20.4-28.8V DC
Output Type: 4 Bits DC outputs.
Digital Input: 6 Bits 24V DC Inputs.
Analog Input: 2 Channels Analog 0-10 V DC input.
Program/data memory: 30 KB
6AG12111AE314XB0_datasheet_enTechnical data and environmental conditions of S7-1200
The following CPUs for the SIPLUS S7-1200 are available for an ambient temperature range from -40 °C to +55 °C or from ?40 °C to +70 °C, as well as versions for extraordinary exposure to media (conformal coating).
- SIPLUS CPU 1211C: The clever, compact solution.
- SIPLUS CPU 1212C: The superior, compact solution.
- SIPLUS CPU 1214C: The compact, high-performance CPU.
- SIPLUS CPU 1215C: The compact, high-end CPU with even more performance.
Environmental conditions | SIPLUS extreme | ||
Ambient temperature range |
-40/-20 to +55/+70°C1) | ||
Relative humidity | 100%100% condensation, condensation and ice formation permitted |
||
Pollutant concentration |
EN60721-3-3 3C4 and ISA S71.04 G1, G2, G3, GX2) |
||
Continuous exposure | Limit value3) | ||
SO2 | 4.8 ppm | 14.8 ppm | |
H2S | 9.9 ppm | 49.7 ppm | |
Cl | 0.2 ppm | 1.0 ppm | |
HCl | 0.66 ppm | 3.3 ppm | |
HF | 0.12 ppm | 2.4 ppm | |
NH | 49 ppm | 247 ppm | |
O3 | 0.1 ppm | 1.0 ppm | |
NOx | 5.2 ppm | 10.4 ppm | |
At RH <75%, condensation permitted | |||
Salt mist | Salt mist test (EN 60068-2-52) | ||
Mechanically active substances |
EN 60721-3-3 3S4 | ||
Dust (suspended solids) | 4.0 mg/m2h | ||
Dust (precipitation) | 40 mg/m2h including sand/dust (“Arizona dust”) |
||
Biologically active substances | EN 60721-3-3 3B2 mold growth, sponge except fauna |
