Connectors for SINAMICS V90 6FX2003 0SL13

Signal connector straight for S-1FL6 HI with rotary pulse encoder 8-pole insulator; union nut Socket contact (0.2-0.25 mm2) for cable diameter 6-8 mm Contents 5 units

Sharing good things

Description

6FX2003-0SL13 6FX20030SL13 Signal connector straight for S-1FL6 HI with rotary pulse encoder 8-pole insulator; union nut Socket contact (0.2-0.25 mm2) for cable diameter 6-8 mm Contents 5 units Connecting-cables-for-SIMATIC-S7-controller

Overview

Couplings and clamps

Couplings

The motion control encoders are driven via a plug-in coupling or spring disk coupling. Alternatively, pulleys can also be used.

Clamps

Motion control encoders with Synchro flange can be axially mounted on the machine with screws or secured with 3 clamps.

Signal connectors as mating connectors

A signal connector is available as a mating connector for motion control encoders with flange outlet or with cable and connector.

The mating connector with 12 contacts is suitable for all incremental encoders.

The mating connector with 17 contacts is suitable for absolute encoders with EnDat.

Signal connector

signal connector is available as a replacement for motion control encoders with cable and connector.

MOTION-CONNECT DRIVE-CLiQ signal cables

Pre-assembled MOTION-CONNECT DRIVE-CLiQ signal cables with M12 plug are available as basic cables and extensions for connecting motion control encoders with DRIVE-CLiQ interface.

Custom made MOTION-CONNECT cable

If you cannot find a proper cable for your application, please send your requests to info@plcskit.com, we will do our best to help you to get the job done.

We offer custom made cable for the product codes below.

6FX5002/6002/8002-2DC10
6FX5002/6002/8002-2CA31
6FX5002/6002/8002-2EQ10
6FX5002/6002/8002-2AH00
6FX5002/6002/8002-2CG00
6FX2002-1DC00/1DC20/2DC00/2DC20
6SL3060-4AB00-0AA0
6SL3060-4AU00-0AA0
6SL3060-4AJ20-0AA0
6SL3060-4AA50-0AA0
6FX5002/6002/8002-2CA21
6FX5002/6002/8002-2CA11
6FX5002/6002/8002-2CA15
6FX5002/8002-5CA01
6FX5002/8002-5CS01
6FX5002/8002-5CN01
6FX5002/8002-5CS11
6FX5002/8002-5CS21
6FX5002/8002-5CS31
6FX5002/8002-5CS41
6FX5002/8002-5CN06
6FX5002/8002-5CN26
6FX5002/8002-5CA31
6FX5002/8002-5CA41
6FX5002/8002-5CA51
6FX5002/8002-5CA61
6FX5008/8008-1BD21/1BD41/1BD51
6FX5008/8008-1BA11/1BB11/1BA21/1BB21
